Introduction of Peanut Butter Processing Line
This peanut butter processing line was designed by combined with domestic and foreign advanced technology and customer demand. It is consisted of feed elevator, continuous roasting & peeling machine, cooling machine, storing and feeding machine, grinding machines, mixing machine, vacuum degassing tank, pump and other spare parts.
Working Principle:
The basic working principle of colloidal grinding is, high-speed shear grinding and high-speed stirring.The relative motion of the Mo gear, which is one of the high-speed rotation, the other static, makes the material pass, and the material is subjected to great shear force and friction.At the same time, in the high frequency vibration and the high-speed vortex, the force of the material is obtained, the grinding,Emulsifier, the homogeneous mix, thus obtains the fine benefit.
Parameters Of Peanut Butter Making Line
Range of Application :
1. Foodstuff industry:aloe, flower dust wall-broken, pineapple, gingili, ice cream, jam, syrup, soy, bean, grass nut milk, dairy produce, malted milk, essence, drinks, emulsified chicken bones, emulsified pigskin and other animal skins.
2.Chemical industry: oil paint, dye, coloring matter, dope, lubrication, lubrication grease, diesel oil, petrol activator, emulsified bitumen, adhesive, scour, plastic, glass steel, etc.
3.Life chemistry : toothpaste, scour, shampoo, shoeshine, cosmetic, bath extractive, soap, sweet-smelling grease etc.
4.Pharmaceutical industry:syrups, nutrition fluid, Chinese medicine, poultice, biology produce, fish liver oil, pollen, queen bee plasma, bacterin, ointments, liquid tonic taken orally, spasmolytic, pancreas and enzyme preparation, emulsion, herd drug etc.
5.Construction industry:dopes including inside and outside walls dope, antisepsis waterproof dope, porcelain dope, colorful dope, pottery and porcelain enamel etc.
6.Other industry:plastic industry, weave industry, paper making industry, biology chemical, environmental protection and economization on energy, coal floatation, universities, scientific research institutes etc.
Introduction of Peanut Butter Processing Line
This peanut butter processing line was designed by combined with domestic and foreign advanced technology and customer demand. It is consisted of feed elevator, continuous roasting & peeling machine, cooling machine, storing and feeding machine, grinding machines, mixing machine, vacuum degassing tank, pump and other spare parts.
Working Principle:
The basic working principle of colloidal grinding is, high-speed shear grinding and high-speed stirring.The relative motion of the Mo gear, which is one of the high-speed rotation, the other static, makes the material pass, and the material is subjected to great shear force and friction.At the same time, in the high frequency vibration and the high-speed vortex, the force of the material is obtained, the grinding,Emulsifier, the homogeneous mix, thus obtains the fine benefit.
Parameters Of Peanut Butter Making Line
| No. | Equipment | Power(kw) | Size(mm) |
| 1 | Lifting Machine | 0.75 | 1000*500*1500 |
| 2 | Peanut Roasting Machine | 118 | 4700*2900*1750 |
| 3 | Stokehold Belt | 0.75 | 5600*500*1500 |
| 4 | Cooling Belt | 8.1 | 8000*1250*1600 |
| 5 | Peanut Peeling Machine | 3 | 2000*800*2200 |
| 6 | Picking Belt | 0.75 | 6000*800*1000 |
| 7 | Lifting Machine | 0.75 | 1000*500*3900 |
| 8 | Storage Hopper | 0.04 | 1100*1100*2900 |
| 9 | Peanut Grinding Machine | 15 | 990*450*1650 |
| 10 | Mixing Tank | 2.2 | 500L |
| 11 | Peanut Butter Grinding Machine | 15 | 990*450*1650 |
| 12 | Mixing Tank | 2.2 | 500L |
| 13 | Continuous Cooling Machine | 0.75 | 2600*400*900 |
| 14 | Vauum Degassing Machine | 3 | 500L |
| 15 | Filling Machine | 0.2 | 1200*400*950 |
Range of Application :
1. Foodstuff industry:aloe, flower dust wall-broken, pineapple, gingili, ice cream, jam, syrup, soy, bean, grass nut milk, dairy produce, malted milk, essence, drinks, emulsified chicken bones, emulsified pigskin and other animal skins.
2.Chemical industry: oil paint, dye, coloring matter, dope, lubrication, lubrication grease, diesel oil, petrol activator, emulsified bitumen, adhesive, scour, plastic, glass steel, etc.
3.Life chemistry : toothpaste, scour, shampoo, shoeshine, cosmetic, bath extractive, soap, sweet-smelling grease etc.
4.Pharmaceutical industry:syrups, nutrition fluid, Chinese medicine, poultice, biology produce, fish liver oil, pollen, queen bee plasma, bacterin, ointments, liquid tonic taken orally, spasmolytic, pancreas and enzyme preparation, emulsion, herd drug etc.
5.Construction industry:dopes including inside and outside walls dope, antisepsis waterproof dope, porcelain dope, colorful dope, pottery and porcelain enamel etc.
6.Other industry:plastic industry, weave industry, paper making industry, biology chemical, environmental protection and economization on energy, coal floatation, universities, scientific research institutes etc.
